Model No.

IDTS – UR88 SL

Frequency range

902-928MHZ(or customized)

Protocol

ISO18000-6B, EPC Class 1 Gen2(18000-6C)

FM mode

FHSS or fixed frequency, set by the software

RF output

30dBm adjustable;50Ω load

Communication interface

LAN,RS232,RS485,Wiegand26/34,IEEE 802.11 (TCP/IP & Wifi Optional)

Power dissipation

average<10W

Application software

Provide with Demonstration Software and SDK

Tag Operation Performance

Reading distance

0 – 15m equipped with 12dbi antenna(tag dependent)

Air interface

EPC global UHF ISO-18000-6C(EPC G2), ISO-18000-6B

Mechanical and Electrical Performance

Dimension

255(L)*255(W)*42(H)mm

Power supply

Equipped with power convertor 220V AC input, +9V/3A DC output

Weight

2.0Kg

Humidity

10% to 95%, non-condensing

Protection grade

IEC IP65

Regulatory

Compliant with CE, FCC

Operation temperature

-20 ºC to +60  ºC
