Uhf Handheld Rfid Reader CX1500N

System

Operation System:

Android 12.0

Language:

Multi-language supportable

CPU:

Octa core MTK 6763 CPU

Frequency:

2.0GHz

Memory Capacity:

LPDDR3: 4GB; iNand FLASH:64GB

Extended Memory:

Max 128G TF Card supportable

UHF RFID

Protocol:

ISO/IEC18000-6C/6B, EPC Global C1Gen2

Frequency:

EU:865-868MHz (ETSI EN 302208)

USA:902 MHz-928MHz (FCC part 15)

CHN:920-925MHz(CMII)

Antenna:

Circular polarization 2dBi

Transmitting Power

0-26dBm

Reading Distance:

0-25m

Other function

GPS precision:

Within 10 meters

WiFi:

IEEE 802.11b/g/n

Bluetooth:

Bluetooth V 4.0

4G Bands:

TDD-LTE Band 38, 39, 40, 41; FDD-LTE Band   1, 2, 3, 4, 7, 17, 20;

Extend port:

1×SD/MMC card slot,2×nano SIM card slot

Battery Parameter

Capacity:

Rechargeable li-ion polymer, 3.7V, 4300mAh

Screen & Keyboard

LCD Screen:

Gorilla Glass 3 9H 5.0 in. IPS (720x1440)touch screen with backlight

Loudspeaker:

Built-in (Volume adjustable)

Keyboard:

Touch and Customized Buttons

Cradle(optional)

Function:

Charging, data transfer

Power supply:

DC 5V

Physical

Working Temperature:

-20°C ~ +55°C

Storage Temperature:

-30°C ~ +70°C

Atmospheric Pressure:

86kPa～108kPa

Relative Humidity:

5%-95% RH (no condensing)

Drop Test:

1.2 meter free fall onto concrete

Size:

178mm(H)x83mm(W)x17mm(D)±2 mm

Weight:

580g

Parts

Cable:

USB cable, DC 5V power supply

Power Supply:

5V/2A adapter
