UHF RFID Pallet Tag IDTS-UPT (128 × 19 mm)
A slim 128 × 19 mm UHF hard tag for tracking wooden and plastic pallets at dock doors and gates. Built for non-metal surfaces, with an omni-directional Monza 4E chip and up to 12 m range at 2 W ERP.
₹45
per piece + 18% GST
Minimum order: 500 pieces · the final price for your quantity is confirmed in the quote
View datasheet PDF · 173 KB- 7-day replacement · 1-year warranty against manufacturing defects
- Blue Dart next-day delivery
- Samples ₹250 (1–2 pcs, incl. shipping) · request
Key features
- Long-range off-metal tag for wooden and plastic pallets
- Impinj Monza 4E with True3D dual antenna ports for omni-directional reads
- Up to 12 m at 2 W ERP; up to 15 m at 4 W ERP
- 496-bit EPC, 128-bit user memory, −14.6 dBm write sensitivity
- Industrial ABS/PC housing; drop and stress tested
- Option to add a barcode label on the front
- Frequency
- 840–960 MHz
- Chip
- Impinj Monza 4E (other chips on request)
- Read range
- Up to 12 m at 2 W ERP; up to 15 m at 4 W ERP
- Operating temperature
- −25 °C to +85 °C
Overview
A long-range UHF RFID pallet tag for non-metal pallets
The UPT is a 128 × 19 × 6 mm bar tag made for pallets with wooden, plastic or other non-metal surfaces. Its long, slim shape fits along the side of a pallet block or deck board, and the ABS/PC housing has passed drop and stress tests. It is not meant for direct mounting on steel; for metal cages and racking, choose a tag from our on-metal range.
Why the chip matters for pallets
Pallets reach a dock-door reader at every angle. The Impinj Monza 4E uses True3D, with two antenna ports that make a compact tag omni-directional, which improves read reliability when a pallet arrives turned. Custom EPC plus TID backscatter speeds up tag authentication, and a write sensitivity of −14.6 dBm helps when you commission and encode tags in bulk. The 496-bit EPC leaves room for longer identifiers; see our EPC encoding guide.
Range and labelling
Expect up to 12 m at 2 W ERP, the limit for readers on India’s 865–868 MHz band (15 m is quoted at 4 W ERP). A barcoded label can be added on the front, so the same pallet can be scanned by RFID at the dock and by barcode where no reader is installed. For dock-door layouts, read our guide to RFID in logistics and supply chain.
Typical applications
- Pallet tracking
- Dock-door verification
- Warehouse put-away
- Pallet pooling
- Pallet returns
Specifications
Datasheet (PDF)| Model | IDTS-UPT |
|---|---|
| Frequency | 840–960 MHz |
| Chip | Impinj Monza 4E (other chips on request) |
| Memory | EPC up to 496 bits; user memory 128 bits |
| Write sensitivity | −14.6 dBm |
| Data retention | 50 years |
| Write endurance | 100,000 cycles |
| Read range | Up to 12 m at 2 W ERP; up to 15 m at 4 W ERP |
| Dimensions | 128 × 19 × 6 mm |
| Weight | 13 g |
| Material | ABS/PC |
| Colour | White, grey, black, orange or blue |
| Printing | Laser engraving, marking or polyester label |
| Mounting surface | Non-metal (off-metal tag) |
| Operating temperature | −25 °C to +85 °C |
| Storage temperature | −25 °C to +65 °C |
| Operating mode | Passive (no battery) |
| Tests | Stress test and drop test passed |
Frequently asked questions
Can the UPT pallet tag be fixed on metal?
How far can the pallet tag be read?
Which chip and memory does it use?
Will pallets be read if they are turned around?
Can I add a barcode to the tag?
